Citroen C5 Aircross I (11.5 kWh)

2024 • SUV

Citroen C5 Aircross I (11.5 kWh) gallery

Electric Range

50

km

Battery Capacity

11.5

kWh

Power Output

181

HP

Range Simulator

Test real-world range with different driving conditions and scenarios

⭐

Safety Rating

Adult Occupant
89%
Child Occupant
88%
Pedestrian
72%
Safety Assist
75%
5/5
Euro NCAP
2024
Source: Euro NCAP

BATTERY

11.5 kWh

Battery size in kilowatt hours

RANGE (KM)

50 km (WLTP)

Mileage in kilometers according to the WLTP/EPA standard

ON-BOARD CHARGER (AC)

3.7 kW standard, 7.4 kW optional

3,7 kW

Maximum charging power AC

MAX CHARGING POWER (DC)

Not supported

Maximum charging power with fast charging/lightning charging

CHARGING SOCKET (AC)

Type 2Mennekes

Charging socket in the car for normal charging

FAST CHARGING (DC)

Not supported

Charging socket in the car for fast charging

General

Brand
Citroen
Model
C5 Aircross I (11.5 kWh)
Year
2024
Segment
SUV
Battery Architecture
modular

Electric Performance

AC Charge Time
3 hours
DC Charge Time
N/A minutes
Battery Chemistry
Li-Ion
Battery Voltage
200V

Engine & Performance

Power
181 HP
Engine
1.598L
Fuel Consumption
1.45 L/100km
CO₂ Emission
32 g/km
Electric Motor Power
110 HP
Emission Standard
Euro 6d

Comfort & Space

Trunk Volume
500 L
Seats
5
Warranty
3 years
Country Availability
DE,FR,UK,PL
Weight
1750 kg
Length
4500 mm
Width
1969 mm
Height
1689 mm
Wheelbase
2730 mm
Max Trunk Volume
500 L

Key Technical Specifications — Citroen C5 Aircross I (11.5 kWh) (2024)

Official manufacturer and WLTP homologated technical data sheet for Citroen C5 Aircross I (11.5 kWh) plug-in hybrid.

Technical specifications sheet for Citroen C5 Aircross I (11.5 kWh) (2024) Plug-in Hybrid
Specification ParameterOfficial Value
Vehicle ModelCitroen C5 Aircross I (11.5 kWh)
WLTP Electric Range50 km
Battery Capacity11.5 kWh
WLTP Fuel Consumption1.45 L / 100 km
CO₂ Emissions32 g / km
System Power Output181 HP (135 kW)
Combustion Engine1.598 L
Electric Motor Output110 HP (82 kW)
AC Charging3.7 kW
DC Fast ChargingNot supported
Seating Capacity5 Seats
Luggage / Boot Capacity500 L (Max: 500 L)
Dimensions (L × W × H)4500 × 1969 × 1689 mm
Curb Weight1750 kg
Euro NCAP Safety★★★★★ (5 Stars)
Manufacturer Warranty3 Years
