Citroen C5 X 1.6

Name: Citroen C5 X 1.6 (2024) Plug-in Hybrid
Brand: Citroen

2024 • Sedan

Electric Range

Battery Capacity

12.4

kWh

Power Output

150

Range Simulator

Test real-world range with different driving conditions and scenarios

⭐

Safety Rating

Adult Occupant

89%

Child Occupant

88%

Pedestrian

72%

Safety Assist

75%

5/5

Euro NCAP

2024

Source: Euro NCAP

BATTERY

12.4 kWh

Battery size in kilowatt hours

RANGE (KM)

54 km (WLTP)

Mileage in kilometers according to the WLTP/EPA standard

ON-BOARD CHARGER (AC)

3.7 kW standard, 7.4 kW optional

3,7 kW

Maximum charging power AC

MAX CHARGING POWER (DC)

Not supported

Maximum charging power with fast charging/lightning charging

CHARGING SOCKET (AC)

Type 2Mennekes

Charging socket in the car for normal charging

FAST CHARGING (DC)

Not supported

Charging socket in the car for fast charging

General

Brand

Citroen

Model

C5 X 1.6

Year

2024

Segment

Sedan

Battery Architecture

modular

Electric Performance

AC Charge Time

3 hours

DC Charge Time

N/A minutes

Battery Chemistry

Li-Ion

Battery Voltage

400V

Engine & Performance

Power

150 HP

Engine

1.598L

Fuel Consumption

1.85 L/100km

CO₂ Emission

32 g/km

Electric Motor Power

110 HP

Emission Standard

Euro 6d

Comfort & Space

Trunk Volume

500 L

Seats

Warranty

3 years

Country Availability

DE,FR,UK,PL

Weight

1751 kg

Length

4805 mm

Width

1815 mm

Height

1485 mm

Wheelbase

2785 mm

Max Trunk Volume

500 L

Key Technical Specifications — Citroen C5 X 1.6 (2024)

Official manufacturer and WLTP homologated technical data sheet for Citroen C5 X 1.6 plug-in hybrid.

Technical specifications sheet for Citroen C5 X 1.6 (2024) Plug-in Hybrid
Specification Parameter	Official Value	Standard / Details
Vehicle Model	Citroen C5 X 1.6	2024 Model Year • Sedan
WLTP Electric Range	54 km	WLTP EAER (Combined pure electric)
Battery Capacity	12.4 kWh	Li-Ion
WLTP Fuel Consumption	1.85 L / 100 km	WLTP Weighted Combined
CO₂ Emissions	32 g / km	Euro 6d homologation
System Power Output	150 HP (112 kW)	ICE + Electric Combined
Combustion Engine	1.598 L	Internal Combustion Engine (ICE)
Electric Motor Output	110 HP (82 kW)	Synchronous electric motor
AC Charging	3.7 kW	Type 2 (Mennekes) AC socket
DC Fast Charging	Not supported	AC Charging only
Seating Capacity	5 Seats	Standard 2-Row Layout
Luggage / Boot Capacity	500 L (Max: 500 L)	VDA measurement method
Dimensions (L × W × H)	4805 × 1815 × 1485 mm	Wheelbase: 2785 mm
Curb Weight	1751 kg	Unladen weight EU
Euro NCAP Safety	★★★★★ (5 Stars)	Adult: 89% • Child: 88%
Manufacturer Warranty	3 Years	Official European warranty coverage
