Ford Kuga

Name: Ford Kuga (2024) Plug-in Hybrid
Brand: Ford

2024 • SUV

Electric Range

Battery Capacity

14.4

kWh

Power Output

243

Range Simulator

Test real-world range with different driving conditions and scenarios

⭐

Safety Rating

Adult Occupant

89%

Child Occupant

88%

Pedestrian

72%

Safety Assist

75%

5/5

Euro NCAP

2024

Source: Euro NCAP

BATTERY

14.4 kWh

Battery size in kilowatt hours

RANGE (KM)

65 km (WLTP)

Mileage in kilometers according to the WLTP/EPA standard

ON-BOARD CHARGER (AC)

3,6 kW

Maximum charging power AC

MAX CHARGING POWER (DC)

Not supported

Maximum charging power with fast charging/lightning charging

CHARGING SOCKET (AC)

Type 2Mennekes

Charging socket in the car for normal charging

FAST CHARGING (DC)

Not supported

Charging socket in the car for fast charging

General

Brand

Ford

Model

Kuga

Year

2024

Segment

SUV

Battery Architecture

modular

Electric Performance

AC Charge Time

3.5 hours

DC Charge Time

N/A minutes

Battery Chemistry

NCM

Battery Voltage

400V

Engine & Performance

Power

243 HP

Engine

2.5L

Fuel Consumption

1.05 L/100km

CO₂ Emission

24 g/km

Electric Motor Power

100 HP

Emission Standard

Euro 6d

Comfort & Space

Trunk Volume

412 L

Seats

Warranty

3 years

Country Availability

DE,FR,UK,IT,ES

Weight

1800 kg

Length

4645 mm

Width

1882 mm

Height

1683 mm

Wheelbase

2710 mm

Max Trunk Volume

1534 L

Key Technical Specifications — Ford Kuga (2024)

Official manufacturer and WLTP homologated technical data sheet for Ford Kuga plug-in hybrid.

Technical specifications sheet for Ford Kuga (2024) Plug-in Hybrid
Specification Parameter	Official Value	Standard / Details
Vehicle Model	Ford Kuga	2024 Model Year • SUV
WLTP Electric Range	65 km	WLTP EAER (Combined pure electric)
Battery Capacity	14.4 kWh	NCM
WLTP Fuel Consumption	1.05 L / 100 km	WLTP Weighted Combined
CO₂ Emissions	24 g / km	Euro 6d homologation
System Power Output	243 HP (181 kW)	ICE + Electric Combined
Combustion Engine	2.5 L	Internal Combustion Engine (ICE)
Electric Motor Output	100 HP (75 kW)	Synchronous electric motor
AC Charging	3.6 kW	Type 2 (Mennekes) AC socket
DC Fast Charging	Not supported	AC Charging only
Seating Capacity	5 Seats	Standard 2-Row Layout
Luggage / Boot Capacity	412 L (Max: 1534 L)	VDA measurement method
Dimensions (L × W × H)	4645 × 1882 × 1683 mm	Wheelbase: 2710 mm
Curb Weight	1800 kg	Unladen weight EU
Euro NCAP Safety	★★★★★ (5 Stars)	Adult: 89% • Child: 88%
Manufacturer Warranty	3 Years	Official European warranty coverage
