Ford C-Max
2015 • MPV
Electric Range
30
kmBattery Capacity
7.6
kWhPower Output
188
HPRange Simulator
Test real-world range with different driving conditions and scenarios
⭐
Safety Rating
Adult Occupant
85%
Child Occupant
86%
Pedestrian
67%
Safety Assist
65%
5/5
Euro NCAP
2015
BATTERY
7.6 kWh
Battery size in kilowatt hours
RANGE (KM)
30 km (WLTP)
Mileage in kilometers according to the WLTP/EPA standard
ON-BOARD CHARGER (AC)
3,6 kW
Maximum charging power AC
MAX CHARGING POWER (DC)
Not supported
Maximum charging power with fast charging/lightning charging
CHARGING SOCKET (AC)
Type 2Mennekes
Charging socket in the car for normal charging
FAST CHARGING (DC)
Not supported
Charging socket in the car for fast charging
General
Brand
Ford
Model
C-Max
Year
2015
Segment
MPV
Battery Architecture
modular
Electric Performance
AC Charge Time
2 hours
DC Charge Time
N/A minutes
Battery Chemistry
NCM
Battery Voltage
300V
Engine & Performance
Power
188 HP
Engine
2L
Fuel Consumption
1.9 L/100km
CO₂ Emission
42 g/km
Electric Motor Power
88 HP
Emission Standard
Euro 6
Comfort & Space
Trunk Volume
432 L
Seats
5
Warranty
3 years
Country Availability
DE,FR,UK,IT,ES
Weight
1650 kg
Length
4380 mm
Width
1828 mm
Height
1620 mm
Wheelbase
2640 mm
Max Trunk Volume
432 L
Key Technical Specifications — Ford C-Max (2015)
Official manufacturer and WLTP homologated technical data sheet for Ford C-Max plug-in hybrid.
| Specification Parameter | Official Value |
|---|---|
| Vehicle Model | Ford C-Max |
| WLTP Electric Range | 30 km |
| Battery Capacity | 7.6 kWh |
| WLTP Fuel Consumption | 1.9 L / 100 km |
| CO₂ Emissions | 42 g / km |
| System Power Output | 188 HP (140 kW) |
| Combustion Engine | 2 L |
| Electric Motor Output | 88 HP (66 kW) |
| AC Charging | 3.6 kW |
| DC Fast Charging | Not supported |
| Seating Capacity | 5 Seats |
| Luggage / Boot Capacity | 432 L (Max: 432 L) |
| Dimensions (L × W × H) | 4380 × 1828 × 1620 mm |
| Curb Weight | 1650 kg |
| Euro NCAP Safety | ★★★★★ (5 Stars) |
| Manufacturer Warranty | 3 Years |
