Ford Escape

Name: Ford Escape (2023) Plug-in Hybrid
Brand: Ford

2023 • SUV

Electric Range

Battery Capacity

14.4

kWh

Power Output

210

Range Simulator

Test real-world range with different driving conditions and scenarios

⭐

Safety Rating

Adult Occupant

89%

Child Occupant

88%

Pedestrian

72%

Safety Assist

75%

5/5

Euro NCAP

2024

Source: Euro NCAP

BATTERY

14.4 kWh

Battery size in kilowatt hours

RANGE (KM)

60 km (WLTP)

Mileage in kilometers according to the WLTP/EPA standard

ON-BOARD CHARGER (AC)

11,0 kW

Maximum charging power AC

MAX CHARGING POWER (DC)

40 kW DC

Maximum charging power with fast charging/lightning charging

CHARGING SOCKET (AC)

Type 2Mennekes

Charging socket in the car for normal charging

FAST CHARGING (DC)

40 kW DC

Charging socket in the car for fast charging

General

Brand

Ford

Model

Escape

Year

2023

Segment

SUV

Battery Architecture

modular

Electric Performance

AC Charge Time

3.5 hours

DC Charge Time

N/A minutes

Battery Chemistry

NCM

Battery Voltage

400V

Engine & Performance

Power

210 HP

Engine

2.5L

Fuel Consumption

1.2 L/100km

CO₂ Emission

27 g/km

Electric Motor Power

90 HP

Emission Standard

Euro 6d

Comfort & Space

Trunk Volume

400 L

Seats

Warranty

3 years

Country Availability

DE,FR,UK,IT,ES

Weight

1750 kg

Length

4610 mm

Width

1882 mm

Height

1683 mm

Wheelbase

2710 mm

Max Trunk Volume

400 L

Key Technical Specifications — Ford Escape (2023)

Official manufacturer and WLTP homologated technical data sheet for Ford Escape plug-in hybrid.

Technical specifications sheet for Ford Escape (2023) Plug-in Hybrid
Specification Parameter	Official Value	Standard / Details
Vehicle Model	Ford Escape	2023 Model Year • SUV
WLTP Electric Range	60 km	WLTP EAER (Combined pure electric)
Battery Capacity	14.4 kWh	NCM
WLTP Fuel Consumption	1.2 L / 100 km	WLTP Weighted Combined
CO₂ Emissions	27 g / km	Euro 6d homologation
System Power Output	210 HP (157 kW)	ICE + Electric Combined
Combustion Engine	2.5 L	Internal Combustion Engine (ICE)
Electric Motor Output	90 HP (67 kW)	Synchronous electric motor
AC Charging	11 kW	Type 2 (Mennekes) AC socket
DC Fast Charging	Yes (40 kW)	CCS / CHAdeMO DC rapid charge
Seating Capacity	5 Seats	Standard 2-Row Layout
Luggage / Boot Capacity	400 L (Max: 400 L)	VDA measurement method
Dimensions (L × W × H)	4610 × 1882 × 1683 mm	Wheelbase: 2710 mm
Curb Weight	1750 kg	Unladen weight EU
Euro NCAP Safety	★★★★★ (5 Stars)	Adult: 89% • Child: 88%
Manufacturer Warranty	3 Years	Official European warranty coverage
