Mazda CX-60

Name: Mazda CX-60 (2025) Plug-in Hybrid
Brand: Mazda

2025 • SUV

Electric Range

Battery Capacity

17.8

kWh

Power Output

328

Range Simulator

Test real-world range with different driving conditions and scenarios

⭐

Safety Rating

Adult Occupant

92%

Child Occupant

83%

Pedestrian

74%

Safety Assist

78%

5/5

Euro NCAP

2022

Source: Euro NCAP

BATTERY

17.8 kWh

Battery size in kilowatt hours

RANGE (KM)

63 km (WLTP)

Mileage in kilometers according to the WLTP/EPA standard

ON-BOARD CHARGER (AC)

11,0 kW

Maximum charging power AC

MAX CHARGING POWER (DC)

40 kW DC

Maximum charging power with fast charging/lightning charging

CHARGING SOCKET (AC)

Type 2Mennekes

Charging socket in the car for normal charging

FAST CHARGING (DC)

40 kW DC

Charging socket in the car for fast charging

General

Brand

Mazda

Model

CX-60

Year

2025

Segment

SUV

Battery Architecture

modular

Electric Performance

AC Charge Time

4 hours

DC Charge Time

N/A minutes

Battery Chemistry

NCM

Battery Voltage

355V

Engine & Performance

Power

328 HP

Engine

2.5L

Fuel Consumption

1.5 L/100km

CO₂ Emission

33 g/km

Electric Motor Power

136 HP

Emission Standard

Euro 6d

Comfort & Space

Trunk Volume

477 L

Seats

Warranty

3 years

Country Availability

DE,FR,UK,IT,ES

Weight

2026 kg

Length

4745 mm

Width

1890 mm

Height

1683 mm

Wheelbase

2870 mm

Max Trunk Volume

1726 L

Key Technical Specifications — Mazda CX-60 (2025)

Official manufacturer and WLTP homologated technical data sheet for Mazda CX-60 plug-in hybrid.

Technical specifications sheet for Mazda CX-60 (2025) Plug-in Hybrid
Specification Parameter	Official Value	Standard / Details
Vehicle Model	Mazda CX-60	2025 Model Year • SUV
WLTP Electric Range	63 km	WLTP EAER (Combined pure electric)
Battery Capacity	17.8 kWh	NCM
WLTP Fuel Consumption	1.5 L / 100 km	WLTP Weighted Combined
CO₂ Emissions	33 g / km	Euro 6d homologation
System Power Output	328 HP (245 kW)	ICE + Electric Combined
Combustion Engine	2.5 L	Internal Combustion Engine (ICE)
Electric Motor Output	136 HP (101 kW)	Synchronous electric motor
AC Charging	11 kW	Type 2 (Mennekes) AC socket
DC Fast Charging	Yes (40 kW)	CCS / CHAdeMO DC rapid charge
Seating Capacity	5 Seats	Standard 2-Row Layout
Luggage / Boot Capacity	477 L (Max: 1726 L)	VDA measurement method
Dimensions (L × W × H)	4745 × 1890 × 1683 mm	Wheelbase: 2870 mm
Curb Weight	2026 kg	Unladen weight EU
Euro NCAP Safety	★★★★★ (5 Stars)	Adult: 92% • Child: 83%
Manufacturer Warranty	3 Years	Official European warranty coverage
