Mitsubishi Eclipse Cross PHEV

Name: Mitsubishi Eclipse Cross PHEV (2024) Plug-in Hybrid
Brand: Mitsubishi

2024 • SUV

Electric Range

Battery Capacity

13.8

kWh

Power Output

141

Range Simulator

Test real-world range with different driving conditions and scenarios

⭐

Safety Rating

Adult Occupant

92%

Child Occupant

83%

Pedestrian

74%

Safety Assist

78%

5/5

Euro NCAP

2022

Source: Euro NCAP

BATTERY

13.8 kWh

Battery size in kilowatt hours

RANGE (KM)

50 km (WLTP)

Mileage in kilometers according to the WLTP/EPA standard

ON-BOARD CHARGER (AC)

3,7 kW

Maximum charging power AC

MAX CHARGING POWER (DC)

Not supported

Maximum charging power with fast charging/lightning charging

CHARGING SOCKET (AC)

Type 2Mennekes

Charging socket in the car for normal charging

FAST CHARGING (DC)

Not supported

Charging socket in the car for fast charging

General

Brand

Mitsubishi

Model

Eclipse Cross PHEV

Year

2024

Segment

SUV

Battery Architecture

modular

Electric Performance

AC Charge Time

3.5 hours

DC Charge Time

N/A minutes

Battery Chemistry

Li-Ion

Battery Voltage

400V

Engine & Performance

Power

141 HP

Engine

2.4L

Fuel Consumption

1.9 L/100km

CO₂ Emission

34 g/km

Electric Motor Power

80 HP

Emission Standard

Euro 6d

Comfort & Space

Trunk Volume

626 L

Seats

Warranty

5 years

Country Availability

Weight

1800 kg

Length

4405 mm

Width

1805 mm

Height

1685 mm

Wheelbase

2670 mm

Max Trunk Volume

1000 L

Key Technical Specifications — Mitsubishi Eclipse Cross PHEV (2024)

Official manufacturer and WLTP homologated technical data sheet for Mitsubishi Eclipse Cross PHEV plug-in hybrid.

Technical specifications sheet for Mitsubishi Eclipse Cross PHEV (2024) Plug-in Hybrid
Specification Parameter	Official Value	Standard / Details
Vehicle Model	Mitsubishi Eclipse Cross PHEV	2024 Model Year • SUV
WLTP Electric Range	50 km	WLTP EAER (Combined pure electric)
Battery Capacity	13.8 kWh	Li-Ion
WLTP Fuel Consumption	1.9 L / 100 km	WLTP Weighted Combined
CO₂ Emissions	34 g / km	Euro 6d homologation
System Power Output	141 HP (105 kW)	ICE + Electric Combined
Combustion Engine	2.4 L	Internal Combustion Engine (ICE)
Electric Motor Output	80 HP (60 kW)	Synchronous electric motor
AC Charging	3.7 kW	Type 2 (Mennekes) AC socket
DC Fast Charging	Not supported	AC Charging only
Seating Capacity	5 Seats	Standard 2-Row Layout
Luggage / Boot Capacity	626 L (Max: 1000 L)	VDA measurement method
Dimensions (L × W × H)	4405 × 1805 × 1685 mm	Wheelbase: 2670 mm
Curb Weight	1800 kg	Unladen weight EU
Euro NCAP Safety	★★★★★ (5 Stars)	Adult: 92% • Child: 83%
Manufacturer Warranty	5 Years	Official European warranty coverage
